About MINI VIBRO SIFTER

18 Inch Mini Vibro Sifter Typical Specifications

Capacity

• Screen Diameter: 18 inch (450 mm)
• Screening Capacity: 50250 kg/hr (depends on material and mesh size)
• Deck Options: Single Deck, Double Deck, Triple Deck

Construction

• Product Contact Parts: SS304 (SS316 optional)
• Non-Contact Parts: SS304 or Powder-Coated MS
• Surface Finish: Mirror polished inside, matte finish outside
• Screen Frame: Stainless steel with food-grade silicone gasket

Drive System

• Vibratory Motor: 0.5 HP
• Power Supply: 230 V Single Phase or 415 V Three Phase
• Motor Speed: 1440 RPM

Approximate Dimensions

• Overall Diameter: 2224 inches (560610 mm)
• Overall Height:
  • Single Deck: 3236 inches (810915 mm)
  • Double Deck: 3642 inches (9151070 mm)
  • Triple Deck: 4248 inches (10701220 mm)

Approximate Weight

• Single Deck: 6080 kg
• Double Deck: 80100 kg
• Triple Deck: 100120 kg

Recommended Installation Space

• Minimum Floor Space: 4 ft 4 ft (1.2 m 1.2 m)
• Recommended Working Area: 6 ft 6 ft (1.8 m 1.8 m)
• Minimum Room Height: 8 ft (2.4 m)

Standard Features

• High-efficiency vibratory motor
• Quick screen replacement
• Adjustable vibration using eccentric weights
• Dust-proof top cover
• Clamp-ring locking system
• Low-noise, low-maintenance operation
• Compact and portable design

Applications

• Pharmaceutical powders and granules
• Food products and spices
• Herbal powders
• Chemical powders
• Cosmetic powders
• Laboratory and pilot plant screening

Available Mesh Sizes

• 10, 20, 40, 60, 80, 100, 120, 150, and 200 mesh (custom mesh sizes available).
